Product Description

Max. Current:   5A
Max. Voltage:   250V
Mechanical Life:   1000000 Times
Switch Combination:   1NO1NC, 1NO, 2NO2NC, 2NO
Place of Origin:   Zhejiang, China
Model Number:   GQ Seriese
Brand Name:   ONPOW
Application:   Industrial Control, Home Appliance, Electric
Head Type:   Round Head, Flat Head
Illuminated Type:   Ring Illuminated
IP level:   IP65
LED:   Yes
Structure:   Mechanical
Terminal Type:   Pin Terminal, Screw Terminal, Plug Terminal
Whether The Smart:   No
Mounting Hole Size:   12mm/16mm/19mm/22mm/25mm/30mm
Material:   Stainless Steel / Aluminium Alloy
Function:   1NO1NC/2NO2NC
LED color:   Red.Yellow.Green.White.Blue.Orange. Double color. Tri-color
Operation type:   Momentary/Latching/Delayed
Certification:   CE RoHS REACH CCC
Protection Level:   IP65/IP67
Selling Units:   Single item
Single package size:   20X13X5 cm
Single gross weight:   0.070 kg
Special Key Feature:   g switch, 3 way switch, hager switch, livolo switch, rf switch, dimmer switch, clap switch, wall switch, euro switch, 220v switch, mk switch, 3com switch, abb switch, zigbee switch, knife switch
Brand:   ONPOW
Mounting hole:   8mm,10mm,12mm,16mm，22mm,25mm,28mm,30mm,40mm
Contact:   1NO1NC,2NO2NC,etc
LED voltage:   6V,12V,24V other voltage could be customized
Housing material:   Stainless steel/Aluminum Alloy/etc
Button material:   Stainless steel/Aluminum Alloy/etc
Electronical life:   50,000 cycles

Rated Voltage: 12 V: 12 V

Rated Voltage: 12 V: 24 V

Rated Voltage: 12 V: 240 V

Size: 12mm(0.47in)

Size: 16 mm(0.63in)

Size: 19 mm(0.75in)

Size: 22 mm(0.87in)

Size: 10mm(0.39in)

Size: 25mm(0.98in)

Size: 30mm(1.18in)

🍪
